Product |
FNSW-4800 |
|
Description |
48-Port 10/100Mbps Fast Ethernet Switch |
|
Hardware Specification |
|
|
Ports |
48 x 10/100Base-TX RJ-45 Auto-MDI/MDI-X ports |
|
Switch Processing Scheme |
Store-and-forward |
|
Address Table |
8K entries |
|
Share data Buffer |
2.5Mbit |
|
Throughput (packet per second) |
6.6Mpps |
|
Switch fabric |
8.8Gbps |
|
Flow Control |
Back pressure for half duplex, IEEE 802.3x Pause Frame for full duplex |
|
Dimensions |
440 x 200 x 44 mm, 1U height |
|
Weight |
2.8 kg |
|
Power Requirement |
100~240VAC, 0.5A, 50-60 Hz |
|
Power Consumption / Dissipation |
27 Watts maximum / 92 BTU/hr maximum |
|
Temperature |
Operating: 0~50 degree C |
|
Humidity Operating |
Operating: 10% to 90% |
|
Standards Conformance |
|
|
Regulation Compliance |
FCC Part 15 Class A, CE |
|
Standards Compliance |
IEEE 802.3 (Ethernet) |
