| SYSTEM PARAMETERS | ||
|---|---|---|
| Storage: | | | Up to 3,000 Valid Cards; Up to 100,000 Event Records; Up to 150,000 Attendance Records |
| Operation System: | | | Linux |
| Fingerprint Capacity: | | | Up to 3000 Fingerprints; Up to 10 Fingerprints for Each Person |
| Fingerprint Recognition Duration: | | | < 1 s |
| FAR (False Accept Rate): | | | ≤0.001% |
| FRR (False Rejection Rate): | | | ≤0.01% |
| Fingerprint Recognizer: | | | Optical Fingerprint Recognizer Module |
| Card Reading Mode: | | | Supports Mifare Card, Including Cards with Special Shapes; Supports Reading Card in Metal Environment |
| Card Reading Distance: | | | 0 to 4.5cm |
| Card Reading Response Duration: | | | < 1 s |
| Fingerprint Comparing Mode: | | | 1:1 and 1:N, N=3000 |
| DEVICE INTERFACES | ||
| Input Interface: | | |
Exit Button × 1, Door Sensor × 1 and Alarm Input × 1
|
| Output Interface: | | | Relay (Lock Output) × 1, and Alarm Output × 1 |
| Transmission Rate: | | | TCP/IP, WIFI: 10/100Mbps Self-adaptive, RS-485: 19200 bps-N-8-1 |
| USB Interface: | | | USB2.0, Type A |
| Communication Interface: | | | TCP/IP, RS-485 (For Secure Door Control Unit), Wiegand Output (W26/W34) and Input (Wiegand 26/34) |
| Wi-Fi: | | | Support |
| External Card Reader: | | | Standard Wiegand26/34 |
| Wiegand Interface: | | | Output: Wiegand 26/34; Input: Wiegand 26/34 |
| GENERAL | ||
| LCD Screen: | | | 2.4-inch (320×240 LCD-TFT Display Screen) |
| Key Board: | | | Keyboard (Back Light) |
| Audio: | | | 1 Buzzer and 1 Loudspeaker |
| Power Supply: | | | 12 VDC/2 A |
| Appearance Color: | | | Black (Included), Gold (Optional), Silver (Optional), White (Optional) |
| Reset Key: | | | × 1 |
| LED Indicator: | | | Power/Status (Red/Green) |
| Water-Proof: | | | IP42 |
| Temper-Proof: | | | Support |
| Installation: | | | Surface Mounting, Metal Door Mounting, Installation with Gang Box |
| Working Temperature : | | | -10° C to 55° C (14° F to 131° F) |
| Working Humidity: | | | 10% to 90% (Non-Condensing) |
| Dimensions (L×W×H): | | | 205 mm × 76.5 mm × 37 mm (8.07″ × 3.01″ × 1.46″) |
